Load Cell IN-S011 100KG C3 Crane Scale Shear Beam Alloy Steel Moistureproof S type weight force sensor 3mV/V

Name: Load Cell INS011 100KG C3 Crane Scale Shear Beam Alloy Steel Moistureproof S type weight force sensor 3mVV
Brand: inntronic
Price: 1 USD

Quality Load Cell IN-S011 100KG C3 Crane Scale Shear Beam Alloy Steel Moistureproof S type weight force sensor 3mV/V for sale

Brand Name : inntronic

Model Number : IN-S011

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T, Western Union, paypal

Delivery Time : 15-30 days

Price : Negotiable

pattern : S Type Silo Load Cell

Capacity : 100kg-20t

output : 2mv/v

Material : Alloy Steel/ Stainless steel

Application : Batching scale, Crane scale

interchangeable brand : HBM

IP protection standard : IP65

accuracy grade : C3

Contact Now

IN-S011 100kg 300kg 750kg 1000kg S Type Silo Load Cell for crane scale, batching scale

Moistureproof Silo Load Cells , Crane Scale S Type Load Cell 100kg - 1000kg for Batching scale

Capacity: 100kg 300kg 750kg 1000kg
Application: Crane scale, test machine, Batching scale

Load Cell IN-S011 100KG C3 Crane Scale Shear Beam Alloy Steel Moistureproof S type weight force sensor 3mV/V

Cable color code :Input: Red(+) Black(-) Output: Green(+) White(-)

Technical specifications		Technical specifications
Rated output(mv/v)	3mV/V	Rated capacity	100--1000 kg
Zero balance	±1.0% FS	Comprehensive precision	±0.03%FS
Input Risistance	350±2	Nonlinearity	±0.03%FS
Output Risistance	380±10	Repeatability	±0.02%FS
Insulation Risistance	≥5000MΩ	Hysteresis	±0.02%FS
Recommendation excitation voltage	10V(DC)	Creep(30minutes)	±0.02%FS
Max excitation voltage	15V(DC)	Returning to zero	±0.02%FS
Temperature characterisitic		Physical characteristic
Compensated temperature range	-10℃-70℃	Safe loading range	120%FS
Operating temperature	-10℃-70℃	Limiting load range	150%FS
Temperature effect on zero	±0.02%FS/10℃	Protection rank	IP65
Temperature effect on output	±0.02%FS/10℃	Cable lenth	3m

Load Cell IN-S011 100KG C3 Crane Scale Shear Beam Alloy Steel Moistureproof S type weight force sensor 3mV/V
